Alpha Blender

Description

Alpha Blender is used when two video sources have to be viewed at the same time. It is a process of combining an image with a background to create the appearance of partial or full transparency.

Product Specifications
  • Blend 2 video source
  • Input format for both the video source: RGB/YCbCr 4:4:4
  • Software programmable Alpha value
  • Pipelined multiplier
  • Latency of 3 clocks

Highlights

  • Alpha value is programmable from the software
