Embedded Technologies, Inc.

i.MX27 System On Module

Description

It is an i.MX27 processor module. It helps developers to prototype their applications on Windows CE 6.0, Android and Linux. As it is in the form of Ready To Manufacture form factors, it can be used as it is in the final product. iWave would offers customization services, if required. It is an ideal solution for customers who are looking for a quick Design Solution to their Embedded Products with the below features. iWave has flexible business models for this platform.

Product Specifications
  • 128MB DDRAM, 32MB+ NAND Flash

  • Optional Onboard

    • 7'' LCD + Touch optional 3.5"LCD
    • USB 1.1 Host or USB 1.1 Device
    • Dual SD, Dual UART
    • VGA out,Audio In/Out, Video IN/OUT
  • Optional

    • Wi-Fi, GSM/GPRS
    • GPS, Camera I/F
    • Keypad I/F & Battery

  • Form Factor: 99mm x 73mm

Highlights

  • Supports multiple OS with different device driversSBC with 15+ design developed around this platform WinCE, Linux, Android

  • Success stories:

    • Rugged Industrial terminal
    • Video phone
    • Protocol converter
    • Patient Monitoring
    • DVR, HMI
