Embedded Technologies, Inc.

TI OMAP Module

Description

Key Benefits

• Low cost solution
• Standard SODIMM connector
• Optimized for HD video acquisition and coding
• Sophisticated video processing, 2D and 3D graphics
• Windows CE 6.0 and Linux BSP freely available

Product Specifications

• 500MHz ARM Cortex-A8 CPU
• NEON SIMD media accelerator
• Hardware 3D engine supporting OpenGL-ES 2. and OpenVG 1.1
• Multiformat HD720 video decoderH
• Dual video output up to SXGA
• High speed USB OTG
• Wide array of interfaces: MMC/SDIO, SPI, I2C, UART, 10/100 Ethernet
• Dual Head display interface
• Commercial and industrial temperature range
