Embedded Technologies, Inc.




  • Supports 6-slot PICMG® backplane
  • Equipped with one 5.25" and one 3.5" front access drive bays
  • Adjustable hold down bar for cards
  • Replaceable and easy-to-clean filter
Product Specifications

Dimensions 7.5 in x 9.7 in x 16.2 in (190.5 mm x 246.4 mm x 411.5 mm)
(W x H x D)
Drive Bays One 5.25” and one 3.5” front accessible drive bay
Two internal 3.5”drive bays
Construction Heavy-duty cold-rolled steel
Color Standard: black
Cooling Fans One 8-cm in-take fan, 49 CFM
Front Panel LEDs: HDD active and system power
System reset switch, ATX Power switch, optional AT power
on/off switch
Two USB connectors
Backplane 6-slot passive backplane
Carton Size 20.9 in x 11.8 in x 15.4 in (530 mm x 300 mm x 390 mm)
Weight Net 7 kg (15.4 lb)


Click Here For DataSheet
